KNITTER-SWITCH Toggle Switch, Panel Mount, On-On-On, 4PDT, Solder Terminal, 250 V ac
Technical Document
Specifications
Brand
KNITTER-SWITCHProduct Type
Toggle Switch
Contact Configuration
4PDT
Switch Operation
On-On-On
Switch Contact Current
4A
Mount Type
Panel
Terminal Type
Solder
Panel Cutout Size
6.2 mm
Actuator Length
10.5mm
Minimum Operating Temperature
-45°C
Contact AC Voltage
250V ac
Actuator Material
Chrome Plated
Maximum Operating Temperature
140°C
Switch Configuration
SPDT, 3PDT, DPDT, 4PDT
Height
35mm
Length
13mm
Standards/Approvals
RoHS
Width
22mm
Series
MTA
Mechanical Life
300000Operations
Country of Origin
China
Product details
Knitter Switch Miniature Toggle Switches - MTA Series
2 and 3 position double pole panel mount toggle switches
Biased and non biased options
Silver contacts
Chrome plated brass actuator and Diallyl Phthalate (UL 94 V-0) case
