E-TEC Right Angle Through Hole Mount PCB Socket, 72-Contact, 2-Row, 2.54mm Pitch, Solder Termination

RS Stock No.: 615-5190Brand: E-TECManufacturers Part No.: BL2-072-A-700-95
brand-logo
View all in PCB Sockets

Technical Document

Specifications

Brand

E-TEC

Number Of Contacts

72

Number Of Rows

2

Pitch

2.54mm

Type

Socket Strip

Mounting Type

Through Hole

Body Orientation

Right Angle

Termination Method

Solder

Current Rating

12A

Voltage Rating

100 V

Contact Material

Beryllium Copper

Product details

Large-diameter tulip contact divisible strips

High-profile divisible strips available in single or double row, straight or angled versions.
These strips feature tin-plated contacts with gold-plated tulips for inserting square pins with a diagonal dimension of 0.65 mm or round pins with a diameter of 0.65 → 0.85 mm.

2.54mm PCB Connector RS Range

A large variety of connector options, to cover the majority of board-to-board, bussing and programming requirements.

Ideate. Create. Collaborate

JOIN FOR FREE

No hidden fees!

design-spark
design-spark
  • Download and use our DesignSpark software for your PCB and 3D Mechanical designs
  • View and contribute website content and forums
  • Download 3D Models, Schematics and Footprints from more than a million products
Click here to find out more
Stock information temporarily unavailable.

₹ 15,392.75

₹ 3,078.55 Each (In a Pack of 5) (Exc. GST)

₹ 18,163.45

₹ 3,632.689 Each (In a Pack of 5) (inc. GST)

E-TEC Right Angle Through Hole Mount PCB Socket, 72-Contact, 2-Row, 2.54mm Pitch, Solder Termination
Imported by:

RS Components & Controls (I) Ltd

Distribution hub - B-89, Sector 67, Noida, Gautam Budh Nagar, (Uttar Pradesh), 201 301

₹ 15,392.75

₹ 3,078.55 Each (In a Pack of 5) (Exc. GST)

₹ 18,163.45

₹ 3,632.689 Each (In a Pack of 5) (inc. GST)

E-TEC Right Angle Through Hole Mount PCB Socket, 72-Contact, 2-Row, 2.54mm Pitch, Solder Termination
Stock information temporarily unavailable.

Stock information temporarily unavailable.

Please check again later.

QuantityUnit pricePer Pack
5 - 120₹ 3,078.55₹ 15,392.75
125 - 370₹ 2,942.74₹ 14,713.70
375 - 995₹ 2,858.66₹ 14,293.30
1000 - 1995₹ 2,779.25₹ 13,896.25
2000+₹ 2,668.08₹ 13,340.40
