Broyce Control Phase, Voltage Monitoring Relay, 3 Phase, DPDT, 243 → 540 V, DIN Rail
Technical Document
Specifications
Brand
Broyce ControlMonitoring Application
Phase, Voltage
Electrical Phase
3
Voltage Sensing Range
243 → 540 V
Contact Configuration
DPDT
Voltage Sensitivity
Undervoltage
Mounting Type
DIN Rail
Phase Sensitivity
Phase Failure, Phase Sequence
Time Delay
0.2 → 10s
Series
L
Minimum Operating Temperature
-20°C
Height
89mm
Width
17.5mm
Maximum Operating Temperature
+60°C
Length
66.5mm
Minimum Voltage Sensed
243 V
Dimensions
66.5 x 17.5 x 89mm
Operating Temperature Range
+60°C
Maximum Voltage Sensed
540V
Terminal Type
Screw
Special Features
Microprocessor Based, Detects Incorrect Phase Sequence, Phase Loss And Neutral Loss, Adjustment For Under Voltage Trip Level, Adjustment For Time Delay
Number of Poles
2
Country of Origin
United Kingdom
Product details
LPRT/2 Phase Failure, Phase Sequence, Under Voltage plus Time Delay
Broyce Controls L-Series signal conditioners use a QR barcode marking method allowing direct access to all technical data sheets, ensuring correct information is always at your finger tips!
Features and Benefits
Compact 17.5 mm DIN Rail housing
Microprocessor based
True R.M.S. monitoring measuring phase to phase (three wire) or phase to neutral (4-wire) voltages
Selectable nominal voltages to suit most popular three wire or 4-wire supply voltages
Monitors own supply and detects an Under voltage condition on one or more phases
Detects incorrect phase sequence, phase loss and neutral loss1
Adjustment for Under voltage trip level
Adjustment for time delay
DPDT relay output 5A
Green LED indication for supply status
Red LED indication for relay status
Approvals
UL Certification
Broyce Monitor Relays
₹ 7,226.04
₹ 7,226.04 Each (Exc. GST)
₹ 8,526.73
₹ 8,526.73 Each (inc. GST)
1
RS Components & Controls (I) Ltd
Distribution hub - B-89, Sector 67, Noida, Gautam Budh Nagar, (Uttar Pradesh), 201 301
₹ 7,226.04
₹ 7,226.04 Each (Exc. GST)
₹ 8,526.73
₹ 8,526.73 Each (inc. GST)
1
Stock information temporarily unavailable.
Please check again later.
