Schneider Electric Harmony Series Push Button Complete Unit, 22mm Cutout

RS Stock No.: 184-6584Brand: Schneider ElectricManufacturers Part No.: XB5S7B2M12
brand-logo
View all in Push Button Switches

Technical Document

Specifications

Brand

Schneider Electric

Panel Cut Out Diameter

22mm

Series

Harmony

Push Button Material

Plastic

Manufacturer Part No.

XB5S7B2M12

Body Material

Plastic, Polyamide

Maximum Operating Temperature

+50°C

Operating Temperature Range

- 5 → +50°C

Minimum Operating Temperature

-5°C

Maximum DC Voltage

30V

Country of Origin

France
