Rosemount 3490 Series Level Controller - Panel Mount ATEX, 115 [arrow/] 230 V ac 1 Current, Voltage Input 1 x 4 - 20mA
Technical Document
Specifications
Brand
RosemountNumber of Inputs
1
Mounting Style
Panel Mount
Probe Voltage
230/115Vac selectable
Supply Voltage
115 V ac, 230 V ac
Overall Length
144.8mm
Overall Width
74.7mm
Overall Depth
173mm
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
+55°C
Hazardous Area Certification
ATEX
Input Type
Current, Voltage
IP Rating
IP40
Output Type
1 x 4 - 20mA + 5 x Relay Outputs
Number of Outputs
1
Series
3490
Current Rating
200 (Fuse) mA, 4 → 20 mA
Isolation Voltage
500V dc
Country of Origin
United Kingdom
Product details
3490 Series Controller
Available either for wall or panel mounting, Rosemount's 3490 series control units are designed for use with any 4-20mA or HART protocol level or flow transmitter. Easy to understand menus and a 'programming wizard' function make programming easy while password protection protect from accidental or unauthorised changes.
Features & Benefits
Tough weatherproof wall mount enclosure for internal and external mounting
Accepts 4–20 mA or HART inputs.
Compatible with HART 5, 6, and 7 Transmitters
Five voltage-free SPDT relays for alarm and control duties
Supports two voltage-free contact closure inputs
4–20 mA 12-bit isolated current output proportional to calculated value
Bright local display of measured value and input/output status
Pre-programmed tank shapes, flow algorithms, and control routines simplify configuration.
A 20-point strapping table facility is provided for non-standard applications
Real-time clock for energy saving routines, pump efficiency calculations, and date/time stamping of data logging
