onsemi, 2 Monostable Multivibrator TTL, 16-Pin SOIC

RS Stock No.: 186-9200PBrand: onsemiManufacturers Part No.: MC14521BDG
brand-logo
View all in Monostable Multivibrators

Technical Document

Specifications

Brand

onsemi

Logic Family

TTL

Product Type

Monostable Multivibrator

Number of Elements per Chip

2

Minimum Pulse Width

120ns

Maximum Quiescent Current

150μA

Minimum Supply Voltage

3V

Mount Type

Surface

Package Type

SOIC

Maximum Supply Voltage

18V

Pin Count

16

Maximum Propagation Delay Time @ CL

15μs

Minimum Operating Temperature

-55°C

Multivibrator Type

Frequency Divider

Maximum Operating Temperature

125°C

Width

4 mm

Height

1.5mm

Length

10mm

Standards/Approvals

No

Series

MC14521

Automotive Standard

AEC-Q100

Country of Origin

China
