MEAN WELL Embedded Switch Mode Power Supply SMPS, MPD-45B, 5 V dc, 24 V dc, 1.2 A, 3.2 A, 44.8W, Dual Output, 127

RS Stock No.: 753-7663Brand: Mean WellManufacturers Part No.: MPD-45B
brand-logo
View all in Switching Power Supplies

Technical Document

Specifications

Brand

Mean Well

Output Voltage

5 V dc, 24 V dc

Output Current

1.2 A, 3.2 A

Power Rating

44.8W

Number of Outputs

2

Input Voltage

127 → 370 V dc, 90 → 264 V ac

Mounting Type

Chassis Mount

Package Type

Open Frame

Length

127mm

Width

76mm

Medical Approved

Yes

Depth

28mm

Minimum Temperature

-10°C

Weight

200g

Maximum Temperature

+60°C

Product details

Mean Well 45W Medical Open Frame AC-DC Power Supply - MPS-45 MPD-45 MPT-45 Series

A range of single output, dual output and triple output 45W open frame AC-DC switch mode power supplies with universal AC input and medical approval to IEC60601-1. These open frame AC-DC switch mode medical power supplies have a compact design, high efficiency, low ripple and noise and are equipped with a built in EMI filter.

Universal AC input
Medical approval IEC60601-1
Max output power of 52W achievable with 18 CFM min forced air convection (apart from 753-7631 which is 35W)
Convection cooled
High efficiency of up to 78%
Low leakage current of <0.3mA
Short circuit, overload and over voltage protection
Fixed switching frequency at 45 KHz
100% full load burn-in test
Built in EMI filter
EMC compliance to EN55011 (CISPR11) Class B
Harmonic current compliance to EN61000-3-2,-3

Approvals

cULus, TUV, CB, CE

Standards

UL2601-1, TUV EN60601-1, IEC60601-1 approved
