JST PH Series Right Angle Through Hole PCB Header, 6 Contact(s), 2 mm Pitch, 1 Row, Shrouded
Technical Document
Specifications
Brand
JSTSeries
PH
Product Type
PCB Header
Pitch
2mm
Current
2A
Number of Contacts
6
Housing Material
Polyamide
Number of Rows
1
Orientation
Right Angle
Shrouded/Unshrouded
Shrouded
Connector System
Wire-to-Board
Mount Type
Through Hole
Contact Material
Brass
Contact Plating
Tin
Minimum Operating Temperature
-25°C
Row Pitch
2mm
Termination Type
Solder
Contact Gender
Male
Maximum Operating Temperature
85°C
Mating Pin Length
3.3mm
Standards/Approvals
No
Voltage
100 V
Product details
JST PH series Shrouded Through Hole Headers
A range shrouded headers for the JST PH series of low-profile 2.0mm pitch wire-to-board connectors. These compact through-hole mounting headers are ideal for high density PCB connections and offer high reliability at low cost. Both top-entry (straight) and side-entry (right-angle) types are available.
