Igus chainflex CF130.UL Control Cable, 18 Cores, 0.5 mm², Unscreened, 25m, Grey PVC Sheath, 20 AWG
Technical Document
Specifications
Brand
IgusSeries
Chainflex CF130.UL
Number of Cores
18
Cross Sectional Area
0.5 mm²
American Wire Gauge
20 AWG
Conductor Material
Bare Copper
Sheath Material
PVC
Sheath Colour
Grey
Screen Type
Unscreened
Screened/Unscreened
Unscreened
Armoured
No
Minimum Bend Radius
5 x D
Length
25m
Outer Diameter
12mm
Voltage Rating
300 V
Current Rating
10 A
Maximum Operating Temperature
+70°C
Fire Behaviour
Flame Retardant
Earth Cable
Yes
Minimum Operating Temperature
-5°C
Oil Resistant
No
Cable Shape
Multicore
Insulation material
TPE
Conductor Resistance
39 Ω/km
Country of Origin
Germany
Product details
Chainflex® PVC Control Cable CF130
Chainflex® PVC control cable is designed for medium load requirements.
Features and Benefits
• Silicon-free
• Without influence of oil
• Not shielded
• Torsion resistant
• Preferably indoor applications
• Flame-retardant in accordance to IEC 60332-1-2, CEI 20-35, FT1, VW1
• Freely suspended travel distances and for gliding applications up to 50 m, Class 2
• Fine-wire stranded conductor consisting of bare copper wires (following EN 60228)
• Outer sheath: Low-adhesion mixture on the basis of PVC, adapted to suit the requirements in Energy Chains® (following DIN VDE 0282 Part 10)
Standards
IEC 60332-1-2, CEI 20-35, FT1, VW1
