Honeywell Bi-Metallic Thermostat, Opens at +150°C, Closes at 135°C, +150°C Max, NC, Automatic Reset, Through Hole Mount

RS Stock No.: 339-724Brand: HoneywellManufacturers Part No.: 2455R--00820235Distrelec Article No.: 30411309
brand-logo
View all in Thermostatic Switches

Technical Document

Specifications

Brand

Honeywell

Minimum Temperature

0°C

Maximum Temperature

+150°C

Opening Temperature

+150°C

Thermostat Type

Bi-Metallic

Closing Temperature

135°C

Switch Configuration

NC

Contact Rating

10A

Contact Voltage Rating

250V ac

Terminal Type

Solder Tab

Mounting Type

Through Hole

Reset Type

Automatic

Country of Origin

China

Product details

Bi-Metallic Thermostat

Snap action bi-metallic disc operates an SPST contact which is electrically isolated from the mounting bracket.
All types reset when the temperature falls to nominally 15° below operating temperature.
• Phenolic body with stainless steel end cap.
• 1/4in tab termination.
• Contacts are rated to 250 Vac 10A with a maximum contact resistance of 50 mΩ.
• Dielectric strength of 2000 Vac.
• N/C types open on temperature rise.
• N/O types close on temperature rise.

Approvals

UL recognised component, CSA Certified

Thermal Switches
