Finder 83 Series Series DIN Rail Mount Timer Relay, 24 → 240V ac/dc, 2-Contact, 0.05-10 min, 0.05-10 s, 0.05-10

RS Stock No.: 759-6656Brand: FinderManufacturers Part No.: 83.82.0.240.0000
brand-logo
View all in Timer Relays

Technical Document

Specifications

Brand

Finder

Supply Voltage

24 → 240V ac/dc

Mounting Type

DIN Rail

Mode of Operation

Star Delta

Time Range

0.05-10 min, 0.05-10 s, 0.05-10 d, 0.05-10h

Number of Contacts

2

Number of Timer Functions

Single

Contact Configuration

DPST

Time Increment

Days, Hours, Minutes, Seconds

Maximum Current

16A

Maximum Voltage

265V ac/dc

Terminal Type

Screw

Switch Configuration

DPDT-NO

Width

22.5mm

Minimum Voltage

16.8V ac/dc

Power Supply

External

Maximum Operating Temperature

+60°C

Length

78.8mm

Minimum Current

16A

Series

83 Series

Depth

100.3mm

Minimum Operating Temperature

-20°C

Time Delay

200ms

Contact Material

Silver Nickel

Country of Origin

Italy

Product details

83 Series Star Delta Timer

22.5 mm wide
Time scales: Type 83.82 - 0.05s → 10 days
Wide supply range 24 → 240 Vac/dc
35 mm DIN rail (EN 60715) mount
