Finder PCB Mount Power Relay, 48V dc Coil, 6A Switching Current, SPDT
Technical Document
Specifications
Brand
FinderCoil Voltage
48V dc
Contact Configuration
SPDT
Mounting Type
PCB Mount
Switching Current
6A
Number of Poles
1
Latching
No
Series
34 Series
Terminal Type
Through Hole
Maximum Switching Voltage AC
400V ac
Maximum Switching Voltage DC
60V dc
Maximum Switching Current AC
10 A
Length
28mm
Coil Resistance
12300Ω
Coil Power
170mW
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
+85°C
Isolation Coil To Contact
6kV
Life
60000 cycles
Contact Material
Silver Alloy
Depth
5mm
Height
15mm
Standards Met
cURus
Number of Coils
Single
Maximum Switching Power AC
1.5 kVA
Application
Compact
Country of Origin
Italy
Product details
34 Series
Ultra-slim, 5mm, package
Cadmium free contact materials
Sensitive DC coil
8 / 8 mm clearance / creepage distance
6 kV insulation, coil-contact
