FCI Panel Mount, 9 Pin Solder D-sub Connector Socket
Technical Document
Specifications
Brand
FCINumber Of Contacts
9
Gender
Female
Body Orientation
Straight
Mounting Type
Panel Mount
Termination Method
Solder
Current Rating
7.5A
Housing Material
Steel
Length
52.65mm
Width
12.55mm
Depth
15.8mm
Dimensions
52.65 x 12.55 x 15.8mm
Contact Plating
Gold over Nickel
Contact Material
Phosphor Bronze
Minimum Operating Temperature
-55°C
Maximum Operating Temperature
+125°C
