Cosel MGS DC-DC Converter, 12V dc/ 900mA Output, 4.5 → 9 V dc Input, 10.8W, PCB Mount, +85°C Max Temp -40°C Min

RS Stock No.: 171-5001Brand: CoselManufacturers Part No.: MGS100512
brand-logo
View all in DC-DC Converters

Technical Document

Specifications

Brand

Cosel

Output Voltage

12V dc

Input Voltage Range

4.5 → 9 V dc

Power Rating

10.8W

Input Voltage Nominal

5 V dc

Output Current

900mA

Mounting Type

PCB Mount

Isolated

Yes

Number of Outputs

1

Package

SIP 8

Isolation Voltage

1kV dc

Width

9.5mm

Depth

12mm

Length

22mm

Series

MGS

Load Regulation

48mV

Minimum Temperature

-40°C

Efficiency

88%

Maximum Temperature

+85°C

Country of Origin

Japan
