Artesyn Switching Power Supply, LCC250-24U-7PE, 24V dc, 10.4A, 250W, 1 Output, 90 → 264V ac Input Voltage
Technical Document
Specifications
Brand
ArtesynOutput Voltage
24V dc
Output Current
10.4A
Power Rating
250W
Number of Outputs
1
Input Voltage
90 → 264V ac
Mounting Type
Chassis Mount
Package Type
Enclosed
Length
177.6mm
Width
101.4mm
Medical Approved
Yes
Depth
37.6mm
Maximum Temperature
+85°C
Minimum Temperature
-40°C
Country of Origin
Philippines
Product details
250W, Switch Mode, Medical Approved, Single Output Embedded Power Supply - LCC250
The LCC250 is a 250 W fully enclosed Power supply, that can deliver full useable power at high temperatures, it comes in a fully sealed enclosure, with IP64 protection, making this Power supply perfect to use for applications in environments where dust or moisture could be an issue, but it’s also suitable for indoor use and medical applications, where the nonexistence of cooling fans can help to reduce dust and noise. The LCC250 comes in a very convenient size, making it ideal for use in limited spaces. These Power supplies have a Universal input, which makes them perfect for use everywhere in the world without any adjustment. The Emerson Network Power LCC250 has a typical high efficiency of 89% and can operate in both constant current and constant voltage mode, allowing it to be used in LED lighting applications. These Power supplies come with Short circuit, overvoltage and over temperature protection.
Power Factor > 0.92 full load
Efficiency 12V / 89%, 24V / 91%, 48V / 91.5%
Remote On/Off Positive or Negative Logic
Single output
Universal input
IP64 Ingress protection
Active PFC
<275μA Leakage Current at 230V ac
2 years warranty
