ABB F200 RCCB, 63A, 4 Pole, 30mA, Type A, 230/400V ac

RS Stock No.: 488-6404Brand: ABBManufacturers Part No.: 2CSF204101R1630 - F204A-63/0.03
brand-logo
View all in RCCBs

Technical Document

Specifications

Brand

ABB

Circuit Breaker Type

RCCB

Current Rating

63A

Number of Poles

4

Trip Sensitivity

30mA

Tripping Characteristics

Type A

Voltage Rating

230/400V ac

Series

F200

Standards Met

RoHS Compliant, UL Recognized

Breaking Capacity at Maximum Voltage Rating

1 kA

Overall Dimensions

69 x 70 x 85mm

Earth Leakage Protection Type

A

Reset Actuator Type

Lever

Overall Width

70mm

Overall Depth

69mm

Overall Length

85mm

Mounting Style

DIN Rail Mount

Rated AC Voltage

230/400V

Country of Origin

Italy

Product details

RCCB, F200 series

Residual current circuit-breaker

2-pin or 4-pin
Detects AC and pulsing DC fault currents
Surge-proof up to 250 A and therefore resistant to short leakage currents to earth
DIN rail assembly

Signal contact / auxiliary switch

1 changeover contact
A maximum of three S2C-S / H6R can be installed in sequence

Approvals

  DIN VDE 0664 part 11, DIN VDE 0664 part 1 // 10.85, EN 61008-2-1
