ERG 1 Way Through Hole Jumper Switch SPST
Technical Document
Specifications
Brand
ERGNumber of Positions
1
Mounting Type
Through Hole
Contact Configuration
SPST
Actuator Type
Slide
Contact Current Rating
1 A
Maximum Operating Temperature
+85°C
Minimum Operating Temperature
-55°C
Operating Temperature Range
-55 → +85°C
Country of Origin
Taiwan, Province Of China
Product details
Jumper Switches
Enabling reliable ON/OFF switching of PCB track signals using a 2.54mm pitch. These switchable jumpers provide an alternative to conventional jumper links by eliminating the need for 'parking pins' on the PCB or exposing bare pins.
Available in single or 16 way breakable versions
Hard gold plated wiper switches with 4 point contact design
Positive location with screwdriver and positive tactile click
Can be used on hand or flow soldered PCBs with minimal wicking (recommended PCB hole dia., single switch 0.8mm, multipole 1.0mm)
2.54mm PCB Connector RS Range
A large variety of connector options, to cover the majority of board-to-board, bussing and programming requirements.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
